  • OpenCV——PS滤镜 水波效果

    // define head function
    #ifndef PS_ALGORITHM_H_INCLUDED
    #define PS_ALGORITHM_H_INCLUDED

    #include <iostream>
    #include <string>
    #include "cv.h"
    #include "highgui.h"
    #include "cxmat.hpp"
    #include "cxcore.hpp"
    #include "math.h"

    using namespace std;
    using namespace cv;

    void Show_Image(Mat&, const string &);

    #endif // PS_ALGORITHM_H_INCLUDED


    #include "PS_Algorithm.h"
    #include <time.h>

    using namespace std;
    using namespace cv;

    #define pi 3.1415926

    int main()
    {
        string Img_name("4.jpg");
        Mat Img;
        Img=imread(Img_name);

        Mat Img_out(Img.size(), CV_8UC3);
        Img.copyTo(Img_out);

        int width=Img.cols;
        int height=Img.rows;
        float A,B;
        A=7;
        B=2.5;

        Point Center(width/2, height/2);

        float r0,r1,new_x,new_y;
        float p,q,x1,y1,x0,y0;
        float theta;

        for (int y=0; y<height; y++)
        {
            for (int x=0; x<width; x++)
            {
                y0=Center.y-y;
                x0=x-Center.x;
                theta=atan(y0/(x0+0.00001));
                if(x0<0) theta=theta+pi;
                r0=sqrt(x0*x0+y0*y0);
                r1=r0+A*width*0.01*sin(B*0.1*r0);

                new_x=r1*cos(theta);
                new_y=r1*sin(theta);

                new_x=Center.x+new_x;
                new_y=Center.y-new_y;

                if(new_x<0)         new_x=0;
                if(new_x>=width-1)  new_x=width-2;
                if(new_y<0)         new_y=0;
                if(new_y>=height-1) new_y=height-2;

                x1=(int)new_x;
                y1=(int)new_y;

                p=new_x-x1;
                q=new_y-y1;

                for (int k=0; k<3; k++)
                {
                    Img_out.at<Vec3b>(y, x)[k]=(1-p)*(1-q)*Img.at<Vec3b>(y1, x1)[k]+
                                            (p)*(1-q)*Img.at<Vec3b>(y1,x1+1)[k]+
                                            (1-p)*(q)*Img.at<Vec3b>(y1+1,x1)[k]+
                                            (p)*(q)*Img.at<Vec3b>(y1+1,x1+1)[k];
                }

            }
        }

        Img_out=Img_out;
        Show_Image(Img_out, "out");

        imwrite("Out.jpg", Img_out);


        waitKey();

    }


    // define the show image
    #include "PS_Algorithm.h"
    #include <iostream>
    #include <string>

    using namespace std;
    using namespace cv;

    void Show_Image(Mat& Image, const string& str)
    {
        namedWindow(str.c_str(),CV_WINDOW_AUTOSIZE);
        imshow(str.c_str(), Image);

    }



    原图


    效果图
