  • PS 图像调整— — gain and bias

        clc;
        clear all;
        close all;

        addpath('E:PhotoShop AlgortihmImage ProcessingPS Algorithm');

        Image=imread('4.jpg');
        Image=double(Image)/255;

        % imshow(Image)
        % set the gain value 0-1
        % set the bias value 0-1

        gain=0.5;
        bias=0.25;

        % adjust the gain
        p=log(1-gain)/log(0.5);

        sz=size(Image);

        T1=Image(:);

        T1(T1<0.001)=0;
        T1(T1>0.999)=1.0;

        ind_1=find(T1>0.001);
        ind_2=ind_1(find(T1(ind_1)<0.5));
        ind_3=find(T1>0.5);
        ind_4=ind_3(find(T1(ind_3)<0.999));

        T1(ind_2)=(2*T1(ind_2)).^p/2;
        T1(ind_4)=1-(2*(1-T1(ind_4))).^p/2;

        cc=(1.0/gain-2)*(1.0-2*T1);

        ind_5=find(T1<0.5);
        ind_6=find(T1>0.5);

        T1(ind_5)=T1(ind_5)./(cc(ind_5)+1);
        T1(ind_6)=(cc(ind_6)-T1(ind_6))./(cc(ind_6)-1.0);

        % adjust the bias

        T1=T1.^(log(bias)/log(0.5));
        T1=T1./((1.0/bias-2)*(1.0-T1)+1);

        Image_new=reshape(T1, [sz(1) sz(2) sz(3)]);

        figure;
        imshow(Image_new);
        imwrite(Image_new, 'out.jpg');

    原图:
    这里写图片描述

    效果图:
    这里写图片描述

    这里写图片描述
