一. 数据集的准备与预处理
1 . 收集dataset
(大量用户名--包含正常用户名与非法用户名)
包含两个txt文件 legal_name.txt ilegal_name.txt. 如下图所示
2. 用文件进行预处理
# Data sets
import os
import pandas as pd
DATAPATH = "../dataset"
POS = os.path.join(DATAPATH, "legal_name.txt")
POS_OUTPUT = os.path.join(DATAPATH, "legal_name.csv")
NEG = os.path.join(DATAPATH, "ilegal_name.txt")
NEG_OUTPUT = os.path.join(DATAPATH, "ilegal_name.csv")
def process_org_data(input_data, output_data, lable):
reader = pd.read_csv(input_data, iterator=True)
while True:
try:
train = reader.get_chunk(10000)
train['username'] = train['username'].astype(str)
train['username'] = map(lambda x: x.strip(), train['username'])
train['length'] = train['username'].apply(len)
... ...
train['label'] = map(lambda x: lable, train['username'])
train.to_csv(output_data, encoding='utf-8', mode='a', index=False, header=False)
except StopIteration:
print "Iteration is stopped."
break
if __name__ == '__main__':
process_org_data(POS, POS_OUTPUT, 1)
process_org_data(NEG, NEG_OUTPUT, 0)
把合法用户dataset与非法用户dataset,合并打乱，切割成 train.csv 和 test.csv
pos_dataset = read_dataset(POS)
neg_dataset = read_dataset(NEG)
dataset = pd.concat([pos_dataset, neg_dataset])
dataset = dataset.sample(frac=1).reset_index(drop=True)
train_data = dataset.loc[:200000, :]
test_data = dataset.loc[200000:, :]
train_data.to_csv(os.path.join(DataPath, "train.csv"), index=False)
test_data.to_csv(os.path.join(DataPath, "test.csv"), index=False)
二. Keras 构建DNN模型进行训练与模型保存
import pandas as pd
import os
import tensorflow as tf
import matplotlib.pyplot as plt
from sklearn.metrics import confusion_matrix
from sklearn.metrics import classification_report
import numpy as np
tf.logging.set_verbosity(tf.logging.INFO)
DataPath = "../dataset"
TRAIN = os.path.join(DataPath, "train.csv")
TEST = os.path.join(DataPath, "test.csv")
COLUMNS = ["username", ... , "label"]
train_dataset = pd.read_csv(TRAIN, skipinitialspace=True, skiprows=1, names=COLUMNS)
test_dataset = pd.read_csv(TEST, skipinitialspace=True, skiprows=1, names=COLUMNS)
for col in train_dataset.columns[1:]:
train_dataset[col] = pd.to_numeric(train_dataset[col], errors='coerce')
for col in test_dataset.columns[1:]:
test_dataset[col] = pd.to_numeric(test_dataset[col], errors='coerce')
X_train = train_dataset.iloc[:, range(1, 19)].values
y_train = train_dataset.iloc[:, 19].values
X_test = test_dataset.iloc[:, range(1, 19)].values
y_test = test_dataset.iloc[:, 19].values
def build_model():
############
model = tf.keras.models.Sequential()
model.add(tf.keras.layers.Dense(64, input_dim=18))
# model.add(tf.keras.layers.BatchNormalization())
model.add(tf.keras.layers.Activation('relu'))
model.add(tf.keras.layers.Dense(32))
# model.add(tf.keras.layers.BatchNormalization())
model.add(tf.keras.layers.Activation('relu'))
model.add(tf.keras.layers.Dense(16))
# model.add(tf.keras.layers.BatchNormalization())
model.add(tf.keras.layers.Activation('relu'))
model.add(tf.keras.layers.Dense(1, activation='sigmoid'))
return
if __name__ == '__main__':
model_file = './my_model.h5'
if (os.path.isfile(model_file)):
print('model file detected. Loading.')
model = tf.keras.models.load_model(model_file)
else:
print('No model file detected. Starting from scratch.')
model = build_model()
model.compile(loss='binary_crossentropy', optimizer="adam", metrics=['accuracy'])
model.fit(X_train, y_train, batch_size=100, epochs=1, validation_data=(X_test, y_test))
三. 导出tensorflow-serving 模型, 运行在线预测服务
def save_model_for_production(model, version, path='prod_models'):
tf.keras.backend.set_learning_phase(1)
if not os.path.exists(path):
os.mkdir(path)
export_path = os.path.join(
tf.compat.as_bytes(path),
tf.compat.as_bytes(version))
builder = tf.saved_model.builder.SavedModelBuilder(export_path)
model_input = tf.saved_model.utils.build_tensor_info(model.input)
model_output = tf.saved_model.utils.build_tensor_info(model.output)
prediction_signature = (
tf.saved_model.signature_def_utils.build_signature_def(
inputs={'inputs': model_input},
outputs={'output': model_output},
method_name=tf.saved_model.signature_constants.PREDICT_METHOD_NAME))
with tf.keras.backend.get_session() as sess:
builder.add_meta_graph_and_variables(
sess=sess, tags=[tf.saved_model.tag_constants.SERVING],
signature_def_map={
'predict':
prediction_signature,
})
builder.save()导出为 tensorflow serving 模型
export_path = "tf-model" save_model_for_production(model, "7", export_path)
运行在线预测服务（tensorflow 官方方法）
/serving/bazel-bin/tensorflow_serving/model_servers/tensorflow_model_server --port=9000 --model_name=username --model_base_path=/data/model/tf-model
四. client通过grpc 调用预测服务
#!/usr/bin/env python
# encoding: utf-8
"""
@version: v1.0
@author: zwqjoy
@contact: zwqjoy@163.com
@site: https://blog.csdn.net/zwqjoy
@file: client
@time: 2018/6/29 15:02
"""
from grpc.beta import implementations
import tensorflow as tf
from tensorflow_serving.apis import predict_pb2
from tensorflow_serving.apis import prediction_service_pb2
import numpy as np
tf.app.flags.DEFINE_string('server', '172.xxx.xxx.xxx:9000',
'PredictionService host:port')
tf.app.flags.DEFINE_string('username', 'demo_user',
'传入一个username')
FLAGS = tf.app.flags.FLAGS
def nametovec(username):
username = username.astype(str)
length = len(username)
... ...
return np.array([length, ...])
def main(_):
host, port = FLAGS.server.split(':')
channel = implementations.insecure_channel(host, int(port))
stub = prediction_service_pb2.beta_create_PredictionService_stub(channel)
# Send request
# See prediction_service.proto for gRPC request/response details.
data = nametovec(FLAGS.username)
data = data.astype(np.float32)
request = predict_pb2.PredictRequest()
request.model_spec.name = 'username' # 这个name跟tensorflow_model_server --model_name="username" 对应
request.model_spec.signature_name = 'predict' # 这个signature_name 跟signature_def_map 对应
request.inputs['inputs'].CopyFrom(
tf.contrib.util.make_tensor_proto(data, shape=(1, 18)))
result = stub.Predict(request, 10.0) # 10 secs timeout
print(result)
if __name__ == '__main__':
tf.app.run()
