java利用POI向Excel(xls)写入图片，并对图片引用超链接

1.maven依赖

<dependency>
	<groupId>org.apache.poi</groupId>
	<artifactId>poi</artifactId>
	<version>3.9</version>
</dependency>

2.代码示例

import java.awt.image.BufferedImage;
import java.io.ByteArrayOutputStream;
import java.io.File;
import java.io.FileOutputStream;
import java.io.IOException;

import javax.imageio.ImageIO;

import org.apache.poi.hssf.usermodel.HSSFCell;
import org.apache.poi.hssf.usermodel.HSSFCellStyle;
import org.apache.poi.hssf.usermodel.HSSFClientAnchor;
import org.apache.poi.hssf.usermodel.HSSFFont;
import org.apache.poi.hssf.usermodel.HSSFHyperlink;
import org.apache.poi.hssf.usermodel.HSSFPatriarch;
import org.apache.poi.hssf.usermodel.HSSFRow;
import org.apache.poi.hssf.usermodel.HSSFSheet;
import org.apache.poi.hssf.usermodel.HSSFWorkbook;
import org.apache.poi.hssf.util.HSSFColor;
import org.apache.poi.ss.usermodel.Hyperlink;

public class WriteImgUtil {

	/**
	 * 写入图片，并插入链接
	 * @param cell 要插入链接的单元格位置
	 * @param sheetName 插入的图片所在的工作表
	 * @param patriarch 画图的顶级管理器，一个sheet只能获取一次，多次插入图片请使用同一个patriarch对象
	 * @param wb HSSFWorkbook对象
	 * @param file 图片文件
	 * @param cellPoint 自定义的对象，指定要插入图片的坐标(x, y)
	 * @return cellPoint 自定义的对象，返回下一个要插入图片的坐标(x, y)
	 * @throws IOException
	 */
	public static CellPoint whiteImg(HSSFCell cell, String sheetName, HSSFPatriarch patriarch, HSSFWorkbook wb, File file, CellPoint cellPoint) throws IOException {
		Hyperlink hyperlink = new HSSFHyperlink(Hyperlink.LINK_DOCUMENT);
        // "'18 Q2截图'"表示sheet页名称  "A10"表示第几列第几行
        hyperlink.setAddress("'18 Q2截图'!A" + (cellPoint.getY() + 1));
        cell.setHyperlink(hyperlink);

        /* 设置为超链接的样式*/
        HSSFCellStyle linkStyle = wb.createCellStyle();
        HSSFFont cellFont= wb.createFont();
        cellFont.setUnderline((byte) 1);
        cellFont.setColor(HSSFColor.BLUE.index);
        linkStyle.setFont(cellFont);
        cell.setCellStyle(linkStyle);

		BufferedImage bufferImg = null;
		ByteArrayOutputStream byteArrayOut = new ByteArrayOutputStream();
		bufferImg = ImageIO.read(file);
		ImageIO.write(bufferImg, "png", byteArrayOut);

		int x1 = cellPoint.getX();
		int y1 = cellPoint.getY();
		int width = bufferImg.getWidth() / 64;
		int height = bufferImg.getHeight() / 18;
		System.out.println(width + "..." + height);

		int x2 = x1 + width;
		int y2 = y1 + height;
		// anchor主要用于设置图片的属性
		HSSFClientAnchor anchor1 = new HSSFClientAnchor(0, 0, 0, 0, (short) x1, y1, (short) x2, y2);
		// 插入图片
		patriarch.createPicture(anchor1, wb.addPicture(byteArrayOut.toByteArray(), HSSFWorkbook.PICTURE_TYPE_PNG));
		cellPoint = new CellPoint(x1, y2 + 1);
		return cellPoint;
	}

	public static class CellPoint {
		private int x;
		private int y;

        public CellPoint(int x, int y) {
	        super();
	        this.x = x;
	        this.y = y;
        }
        public int getX() {
        	return x;
        }
        public void setX(int x) {
        	this.x = x;
        }
        public int getY() {
        	return y;
        }
        public void setY(int y) {
        	this.y = y;
        }
	}

	public static void main(String[] args) {
		FileOutputStream fileOut = null;

		// 先把读进来的图片放到一个ByteArrayOutputStream中，以便产生ByteArray
		try {
			HSSFWorkbook wb = new HSSFWorkbook();
			HSSFSheet sheet1 = wb.createSheet("test href");
			String sheetName = "18 Q2截图";
			HSSFSheet sheet2 = wb.createSheet(sheetName);
			// 画图的顶级管理器，一个sheet只能获取一个（一定要注意这点）
			HSSFPatriarch patriarch = sheet2.createDrawingPatriarch();
			CellPoint cellPoint = new CellPoint(0, 1);
			for (int i = 0; i < 10; i++) {
				HSSFRow row = sheet1.createRow(i);
				HSSFCell cell = row.createCell(0);
				// 点击进行跳转
		        cell.setCellValue("第" + (i + 1) + "个图片链接");

		        File file = null;
		        if (i%2 == 0) {
		        	file = new File("C:/Users/dulinan/Desktop/3333.png");
		        } else {
		        	file = new File("C:/Users/dulinan/Desktop/Desert.jpg");
		        }


				cellPoint = whiteImg(cell, sheetName, patriarch, wb, file, cellPoint);
			}


			fileOut = new FileOutputStream("F:/测试Excel3.xls");
			// 写入excel文件
			wb.write(fileOut);
			System.out.println("----Excle文件已生成------");
		}
		catch (Exception e) {
			e.printStackTrace();
		}
		finally {
			if (fileOut != null) {
				try {
					fileOut.close();
				}
				catch (IOException e) {
					e.printStackTrace();
				}
			}
		}
	}
}
