java PropertyDescriptor 应用及源码分析

java PropertyDescriptor 应用及源码分析

1. 概述

PropertyDescriptor描述Java Bean中通过一对存储器方法（getter / setter）导出的一个属性。我们可以通过该PropertyDescriptor对bean中的该属性进行读取和写入操作，也可以设置其getter / setter。

2. 关键接口及内部属性

public PropertyDescriptor(String name, Class<?> beanClass) throws IntrospectionException
public PropertyDescriptor(String name, Class<?> beanClass, String getMethodName, String setMethodName) throws IntrospectionException
public PropertyDescriptor(String name, Method readMethod, Method writeMethod) throws IntrospectionException

public Class<?> getPropertyType()
public Method getReadMethod()
public Method getWriteMethod()

public void setReadMethod(Method readMethod) throws IntrospectionException
public void setWriteMethod(Method writeMethod)
public boolean equals(Object o)

相关的PropertyDescriptor内部属性如下：
Class<?> propertyType; //该属性的类型
Method getMethod; //getter
Method setMethod; //setter
还有继承自其父类FeatureDescriptor的功能，用于指定该属性的编程名称

3. 简单应用

现有Person类如下：

package com.cwind.property;

public class Person {
        private String name ;
        private int age ;

        public Person(){ this.name = ""; this.age = 0; }
        public Person(String name, int age) { super(); this.name = name; this. age = age; }

        public String getName() { return name; }
        public void setName(String name) { this. name = name; }

        public int getAge() { return age; }
        public void setAge(int age) { this. age = age; }

        public String getNameInUpperCase(){
               return this .name .toUpperCase();
       }
        public void setNameToLowerCase(String name){
               this.name = name.toLowerCase();
       }
}

该类中除了name和age两个属性的标准getter和setter之外，还有增加了一个获取大写name的get方法和一个将name设置为小写的set方法。
在测试类中，首先获得这两个方法对象。

Class personClass = Class.forName("com.cwind.property.Person");
Method read = personClass.getMethod("getNameInUpperCase", null);
Method write = personClass.getMethod("setNameToLowerCase", String.class );

//然后可以通过两种方式构造PropertyDescriptor
PropertyDescriptor prop1 = new PropertyDescriptor( "name", Person.class );     //使用其标准getter和setter
PropertyDescriptor prop2 = new PropertyDescriptor( "name", read, write);     //使用read和write两个方法对象所自定义的getter和setter

//下面构建一个Person对象
Person person = new Person("Kobe" , 36);
System. out.println(prop1.getReadMethod().invoke(person, null));     // --实际调用Person.getName(), result: Kobe
System. out.println(prop2.getReadMethod().invoke(person, null));     // --实际调用Person.getNameInUpperCase(), result: KOBE

prop1.getWriteMethod().invoke(person, "James");     // --实际调用Person.setName(), person.name被设置为James
prop2.getWriteMethod().invoke(person, "James");     // --实际调用Person.setNameToLowerCase(), person.name被设置为james

4. 源码分析

构造函数1：

public PropertyDescriptor(String name, Class<?> beanClass)
        throws IntrospectionException {
        setName(name);     //设置属性编程名，本例中即'name'
        if (name.length() == 0){
            throw new IntrospectionException("empty property name");
// 编程名为空则抛出异常
        }
        String caps = Character.toUpperCase(name.charAt(0)) + name.substring(1);
// 标准getter应为getName()或isName(), 先将首字母大写
        findMethods(beanClass, "is" + caps, "get" + caps, "set" + caps);
// 参数依次为：类类型，可能的getter函数名1，可能的getter函数名2，setter函数名
        if (getMethod == null){   // findMethods()设置PropertyDescriptor的getMethod和setMethod属性
            throw new IntrospectionException(
                "Cannot find a is" + caps + " or get" + caps + " method");
        }
        if (setMethod == null){
            throw new IntrospectionException(
                "Cannot find a " + caps + " method" );
        }
        propertyType = checkMethods(getMethod, setMethod);
// checkMethods()函数用来检测getMethod得到的类型与setMethod的参数类型是否匹配，若匹配则置propertyType为该类型
    }

构造函数2：
public PropertyDescriptor(String name, Class

private void findMethods(Class beanClass, String getMethodName1, String getMethodName2, String setMethodName) throws IntrospectionException {
        try {
            // 首先查找getMethodName1指定的getter (isXXX)
            if (getMethodName1 != null) {
                try {
                    getMethod = beanClass.getMethod(getMethodName1, new Class[0]);
                }
                catch (NoSuchMethodException e)
                {}
            }
            // 若失败，则查找getMethodName2指定的getter (getXXX)
            if (getMethod == null && getMethodName2 != null) {
                try {
                    getMethod = beanClass.getMethod(getMethodName2, new Class[0]);
                }
                catch (NoSuchMethodException e)
                {}
            }
            if (setMethodName != null) {
                if (getMethod != null) {
                    // 如果得到了getMethod，则通过其返回值类型决定setMethod的参数类型
                    Class propertyType = getMethod.getReturnType();
                    if (propertyType == Void.TYPE) {
// 若getter的返回值为Void类型则抛出异常
                        String msg = "The property's read method has return type 'void'";
                        throw new IntrospectionException(msg);
                    }

                    Class[] setArgs = new Class[] { propertyType };
                    try {
                        setMethod = beanClass.getMethod(setMethodName, setArgs);
// 通过函数名和参数类型获得setMethod
                    }
                    catch (NoSuchMethodException e)
                    {}
                }
                else if (getMethodName1 == null && getMethodName2 == null) {
                    // getMethodName1和2均为空，则此属性为只写属性，此时遍历bean中的函数，返回第一个名称与setMethodName一致且返回类型为Void的单参数函数
                    Method[] methods = beanClass.getMethods();
                    for (int i = 0; i < methods.length; i++) {
                        if (methods[i].getName().equals(setMethodName)
                            && methods[i].getParameterTypes().length == 1
                            && methods[i].getReturnType() == Void.TYPE) {
                            setMethod = methods[i];
                            break;
                        }
                    }
                }
            }
        }
        catch (SecurityException e) {
            String msg = "SecurityException thrown on attempt to access methods.";     // 作者在纠结要不要修改异常类型
            throw new IntrospectionException(msg);
        }
    }

checkMethods方法

private Class<?> checkMethods(Method readMethod, Method writeMethod) throws IntrospectionException {
        Class<?> newPropertyType = propertyType;
         // 合法的read方法应该无参同时带有一个非空的返回值类型
        if (readMethod != null) {
            if (readMethod.getParameterTypes().length > 0) {
                throw new IntrospectionException("read method has unexpected parameters");
            }
            newPropertyType = readMethod.getReturnType();
             if (newPropertyType == Void.TYPE) {
                throw new IntrospectionException("read method return type is void");
            }
        }
         // 合法的write方法应该包含一个类型相同的参数
        if (writeMethod != null) {
            if (writeMethod.getParameterTypes().length != 1) { // 参数不能超过一个
                String msg = "write method does not have exactly one parameter" ;
                throw new IntrospectionException(msg);
            }
            if (readMethod == null) {
                // 若无read方法，属性类型就应为writeMethod的参数类型
                newPropertyType = writeMethod.getParameterTypes()[0];
            }
            else {
                // 检查read方法的返回值类型是否与write方法的参数类型相匹配
                if (newPropertyType != null
                    && !newPropertyType.isAssignableFrom(
                        writeMethod.getParameterTypes()[0])) {
                     throw new IntrospectionException("read and write method are not compatible");
                }
            }
        }
         return newPropertyType;
    }

最后提一句PropertyDescriptor.equals(), 只有当属性类型、标志、读写方法和PropertyEditorClass均相同时才认为两个PropertyDescriptor相等

return samePropertyType
                && sameFlags
                && sameReadMethod
                && sameWriteMethod
                && samePropertyEditorClass;

转载自：http://cwind.iteye.com/blog/2028208?utm_source=tuicool

参考：http://blog.csdn.net/z69183787/article/details/8443777
